Diamond Micro Powder

Home » Products » Synthetic Diamond Grits » Diamond Micro Powder

For ferrous lapping, polishing, finishing and super-finishing applications, are widely used in the manufacture of honing whetstones for superior cutting performance and long life, suited for resin, metal, electroplated & vitreous bonding systems, they also can be used in lapping compound, polycrystalline blank & polycrystalline compact producing.

Difference Between Metal Bonded & Electroplated

Quality	Metal Bonded' Grade	Electroplated' Grade
Impurity	A little	Almost any
Crystal shape	A little needle or flake	Almost all sphericity
Size range	Width	Narrow

Raw material is adopted from high-intensity and low impurity content diamonds, special technologies for high-intensity diamond micro-powder in which the crashing, forming process are quite different from those of other techniques, high intensity, strong grinding, high abrasion-resistance, high purity.

Usage : suggested to be applied in the lapping and fine grinding, abrasion and polishing of metal and ceramic bond parts, fine polishing and super polishing of work-piece, production of abrasive paste and agent.

We supply this fine powder in 2 grades :

A and AA (Free sample less than 100ct for testing)

Product Details

Micron (um)	U.S. Standard	F.E.P.A	Mesh size	Application
0-0.025	1/4	-	-	Polishing
0-0.5	-	-	-
0-1	1/2	-	60,000
0-2	1	M1	15,000
1-2	-	-	13,000
1-3	2	-	11,000
2-3	-	M2.5	9,000
2-4	3	-	8,000
3-5	4	-	6,500
4-6	5	-	4,000
4-8	6	M6.3	3,000
5-10	-	-	2,500
6-12	9	-	1800	Lapping
8-16	12	-	1500
10-20	15	M16	1200
12-22	17	-	1100
15-25	20	-	1000
20-30	25	M25	800
22-36	30	-	700
30-40	35	M40	600	Grinding
36-54	45	-	500
40-60	50	-	400/500
54-80	-	M63	325/400
60-100	-	-	-

To enquire about the desired product(s), just check the box and then click “Enquiry Now” button which is provided below.
